LT PVC / XLPE
POWER CABLES

LT PVC / XLPE POWER CABLES

Product Range

1100 Volts Grade, Armoured / Unarmoured Single Core / Multi Core Cables
Single Core Cables upto 1000 Sq.mm
Multicore Cables upto 630 Sq.mm

Technical Parameters

Voltage Grade	1100 Volts
Relevant Standards	IS:7098/Part-1/1988, IS:1554/Part-1/1988, IEC-60502 and BS:5467
Number of Cores	Single Core to Four Core
Cross Sectional Area	Single Core Cables – 1.5 Sq.mm to 1000 Sq.mm as per Spec. / IS Multicore Cables – 1.5 Sq.mm to 630 Sq.mm as per Spec. / IS
Type of Conductor	Copper / Aluminium
Type of Insulation	XLPE / HR PVC / PVC
Inner Sheath	Extruded PVC / FR / FRLSH / ZERO HALOGEN HALOGEN (LSZH) (ST-1) or (ST-2)

Cable Code

A: Aluminium Conductor (when type designation doesn’t contain ‘A’ in the beginning then cable is with Copper Conductor)
2X: At first or second place in type designation, it stands for XLPE insulation
Y: -At first or second place in type designation, it stands for PVC insulation
W: Streel Round Wire Armour
F: Steel Strip Armour
Y: When last in type designation, it stands for PVC Outer Sheath

Type of Armouring

Multicore Cables	Material : Galvanised Steel Type: Round Wire / Flat Strip
Single Core Cables	Material :Nonmagnetic Aluminium Type :Round Wire / Flat Strip
Outer Sheath	Extruded PVC / FR / FRLSH / ZERO HALOGEN (LSZH) (ST-1) or (ST-2)
Drum Lengths	500 / 1000 Mtrs.
Tolerance	+/- 5%
